2022 Mercedes Sprinter 4×4

Purchased new in August 2022. This van has been meticulously built and cared for in the process. Family plans/priorities are shifting and I am selling to make room for a new project. This is a diy project that is about 95% done. The interior was completed with the Adventure Wagon kit and traverse bed system. The electrical system is also complete, though I still have a side panel to add on the 80/20 housing that encloses the components. What’s left is trimming out the steps and adding whatever water system you prefer. I have a temporary electrical shelf mounted that controls the overhead lights and heater controller, but it needs to be finished into a closed panel.

Build components:

Suspension: Van Compass 6.3 adjustable suspension (professionally installed by Peak10 customs in Loveland, CO) plus the Van Compass mudflap relocation kit

Wheels: Set of 5 Black Rhino Arsenals

Tires: Set of 5 BFG KO2 285/75/17 (34 inches). They were added at 1938 miles and have had one tire rotation.

Exterior:

Owl Vans rear ladder and tire carrier

Owl Vans rear door badge to allow for 34” rear tire

Owl Vans side steps

Flatline Van Co Safari Roof Rack w/ KC 50” Gravity LED Pro6 Light Bar

Flatline Van Co Side Ladder

Fiamma F45s awning

AM Auto sliding windows (both passenger and driver’s side)

Maxx Fan

Flarespace Flares w arctic tern window

Hein Fiamma arm mounting brackets

Interior:

Adventure Wagon interior kit w/ black anodized track

Adventure Wagon traverse bed and mattress

Adventure Wagon Mule bag (green)

Espar S2D2 heater

Titan Vans removable rear seat (can be configured to face frontways or sideways looking out of the side door)

Killzmat sound deadening

3M 600 insulation throughout van

Scopema Swivel Seats

4 season insulated floor (1” polyiso board w/ minicell, birch plywood, and lonseal on top)

Weathertech Floor mats

Vancillary overhead shelf

Electrical:

400ah Renogy Lithium Ion batteries

Victron BMV-712 battery monitor

Victron Lynx Distributor power hub

12/3000812-50 120v inverter/chargerVictron Multiplus

Blue Sea 12V distribution panel

Paneltronics 120v breaker panel

Nations 280 amp dual alternator kit

Wakespeed WS500 regulator

Shore power kit (not installed)

SwitchPros 9100 controller

Pedal Controller 2.0

Accessories:

Wanderful insulated window covers for all windows
